JDRG Woodworking Machinery

Equipment category

Drilling Machines

Multi-spindle and panel drilling equipment. Confirm spindle layout, working range and configuration before ordering.

Request a recommendation
Drilling Machines

Selection guide

How to choose a woodworking drilling machine

Drilling equipment is selected by hole pattern, face and edge operations, workpiece range and setup frequency. A workshop producing repeated cabinet parts may value fast multi-spindle patterns, while mixed custom work may need more flexible positioning.

Provide drawings that show hole diameter, depth, spacing and drilling direction. Include panel dimensions, material, batch size, reference edges and whether drilling must connect with an existing line or software process.

Key factors to compare

Factor
What to confirm
Why it matters
Hole pattern
Diameter, depth, pitch and number of simultaneous holes
Determines spindle layout and drilling method.
Drilling direction
Top, bottom, horizontal and multi-face requirements
Defines how many setups or drilling units are needed.
Workpiece range
Panel length, width, thickness and minimum part size
Confirms clamping and positioning compatibility.
Batch and changeover
Repeated patterns, mixed batches and setup frequency
Guides the choice between fixed and programmable solutions.
Line integration
Barcode, software, infeed and outfeed requirements
Matters when drilling is part of a connected workflow.

Available equipment

Primary model pages

Browse one clear page for each model or product group. Additional configurations remain available; contact us if you do not see the exact process you need.

Buying questions

Drilling Machines FAQ

These answers help prepare a useful configuration request. Final technical data is confirmed for the selected machine.

Show panel size, reference edges, hole diameter, depth, pitch, drilling face and tolerances, plus the expected batch size.

It is useful when repeated hole patterns can be drilled together and the spindle arrangement matches the product design.

Some configurations can be planned for line handling or digital job data. The required interfaces must be confirmed before ordering.

Discuss this category

Get a configuration matched to your production

Tell us your material, dimensions, target output, electrical standard and destination.
